Airflow

1. What is Airflow?

Airflow is a platform to programmatically author, schedule, and monitor workflows (DAGs).

2. Key Concepts

• DAG (Directed Acyclic Graph): Defines the workflow structure.

• Task: A unit of work (e.g., running a Python function).

• Operator: Defines what kind of work a task does (PythonOperator, BashOperator, etc.).

• Scheduler: Triggers task execution based on schedule.

• Web UI: Lets you monitor and manage DAGs.

What Exactly Is Airflow?

Airflow is a workflow orchestrator.

It:

• Schedules tasks

• Tracks dependencies

• Retries on failure

• Shows status in UI

2️⃣ Core Airflow Concepts (VERY IMPORTANT)

🔹 DAG (Directed Acyclic Graph)

A DAG = workflow.

• Nodes → tasks

• Edges → dependencies

• A DAG never loops

Example:

extract → transform → load

---

🔹 Task

A task = one unit of work

Examples:

• Run a Python function

• Run a shell command

• Trigger another DAG

---

🔹 Operator

Operator = template for a task

Examples:

• BashOperator

• PythonOperator

• KubernetesPodOperator

👉 You never write tasks directly, you instantiate operators.

---

🔹 DAG Run vs Task Instance

This confuses everyone initially.

---

3️⃣ Airflow Architecture (Understand This Once)

Airflow has 4 main components:

🧠 Scheduler

• Reads DAGs

• Decides when tasks should run

• Puts tasks in queue

If scheduler dies → nothing runs

---

👷 Worker

• Executes the task

• Runs bash/python/etc.

If worker dies → task retries

---

🌐 Webserver

• UI only

• Does NOT run tasks

If webserver dies → UI down, jobs still run

---

🗄️ Metadata DB

• Stores:

  • DAG state

  • Task status

  • Execution history

If DB dies → Airflow is blind

---

4️⃣ Your First Clean DAG (Simple but Correct)

from airflow import DAG
from airflow.operators.bash import BashOperator
from airflow.utils.dates import days_ago
from datetime import timedelta

default_args = {
    "retries": 2,
    "retry_delay": timedelta(minutes=5),
}

with DAG(
    dag_id="airflow_basics_dag",
    start_date=days_ago(1),
    schedule_interval="@daily",
    catchup=False,
    default_args=default_args,
) as dag:

    hello = BashOperator(
        task_id="hello_task",
        bash_command="echo 'Hello Airflow'"
    )

    hello

Key things to notice:

• catchup=False → prevents backfill storm

• retries → reliability

---

5️⃣ Scheduling (VERY IMPORTANT)

⚠️ Airflow runs for previous time window, not “now”.

This is why people say:

“Why is my DAG not running today?”

---

6️⃣ Retries, Timeouts & Failure

Retries

retries=3
retry_delay=timedelta(minutes=10)

Timeout

execution_timeout=timedelta(minutes=30)

Failure behavior

• Task fails → retries

• Retries exhausted → task fails

• DAG marked failed

---

7️⃣ Logs (Where to Look Always)

Every task has logs:

DAG → Task → Logs

Logs show:

• Command run

• Error

• Exit code

👉 80% of Airflow debugging = reading logs.

---

8️⃣ Catchup & Backfill (Beginner Trap 🚨)

catchup=True

Airflow runs all past dates since start_date

catchup=False

Only current execution

👉 In production:
Always catchup=False unless you really know why

---

9️⃣ XCom (Data Passing)

XCom = small data sharing between tasks.

return "hello"

Then:

{{ ti.xcom_pull(task_ids='task1') }}

⚠️ Not for large data.

---

10️⃣ Common Beginner Mistakes (Avoid These)

❌ start_date = datetime.now()
❌ missing retries
❌ long tasks in PythonOperator
❌ assuming webserver runs tasks

---

🧠 Pause & Absorb

Before moving forward, you should be able to answer:
1️⃣ What does scheduler do?
2️⃣ Difference between DAG run & task instance?
3️⃣ Why catchup=False is important?

---
